Panta Surge® 42 Set
Flow pump and shaft-driven pump up to 11,280 l/h
Out of stock
Description
PantaSurge® 42 per flow pump/shaft machine
Rated input voltage: 100–240 V AC, 50/60 Hz
Motor operating voltage: 24 V
Motor operating voltage: 24 V
Max. power consumption: 33 W
Minimum speed: 400 rpm
Max. speed: 2,350 rpm
Max. flow rate: 11,280 l/h
Max. media speed: 3.3 m/s
Axial thrust: ~5.5 N
Max. operating depth: 5.0 m
Weight (motor + basket): 0.408 kg
Total weight: 1.5 kg
Max. fluid temperature: 35 °C
Max. ambient temperature: 40 °C
Magnetic mount for glass thicknesses up to: 19 mm
Magnetic mount for glass thicknesses up to: 19 mm
Cable length: 5.0 m
Additional information
| Shipping weight | 1,05 kg |
|---|
